Molaris TMR (Total Mixed Ration) mešalica predstavlja idealno rešenje za savremene stočarske farme. Njena jednostavna, izdržljiva i lagana konstrukcija čini je najboljim izborom za manje farme koje se bave mlečnim i tovnim govedarstvom.
Vertikalni puž, opremljen specijalno oblikovanim noževima, efikasno seče i okrugle i kvadratne bale u vrlo kratkom vremenu, obezbeđujući ravnomerno izmešan, homogen obrok u kombinaciji sa ostalim hranivima i aditivima.
Zahvaljujući inovativnom dizajnu puža i mešalne kade, nema mrtvih uglova – što doprinosi većem stepenu higijene u poređenju sa klasičnim mešalicama. Nakon istovara, u kanti ne ostaju ostaci hrane, što dodatno pojednostavljuje održavanje.
Opremljena izdržljivim menjačem, ova mešalica garantuje dug radni vek i manju potrošnju energije u poređenju sa horizontalnim sistemima mešanja. Uz opcioni elektronski sistem za merenje, omogućena je precizna kontrola unosa i efikasna priprema obroka.
| TEHNİČKA SPECİFİKACİJA | UNIT | MODEL | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MOLARIS 3 | MOLARIS 6 | MOLARIS 8 | MOLARIS 10 | MOLARIS 12 | MOLARIS 12D | MOLARIS 14D | MOLARIS 16D | MOLARIS 18D | MOLARIS 20D | MOLARIS 24D | MOLARIS 30T | ||
| Volume | m3 | 3 | 6 | 8 | 10 | 12 | 12 | 14 | 16 | 18 | 20 | 24 | 30 |
| Width | mm | 1565 | 2070 | 2100 | 2350 | 2350 | 2200 | 2300 | 2400 | 2400 | 2400 | 2450 | 2500 |
| Length | mm | 3900 | 4200 | 5100 | 5700 | 5800 | 6200 | 6620 | 7000 | 7200 | 7500 | 7500 | 9850 |
| Height | mm | 2125 | 2500 | 2800 | 2820 | 3050 | 2730 | 2750 | 2850 | 2850 | 2870 | 3000 | 3000 |
| Weight | kg | 1400 | 2200 | 3850 | 4100 | 4200 | 4850 | 5000 | 5250 | 5750 | 6000 | 6500 | 8000 |
| Max. Loaded Weight | kg | 2300 | 4000 | 6850 | 7000 | 7800 | 7800 | 9200 | 10000 | 11000 | 12000 | 14000 | 17000 |
| Scale System | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | |
| Scale System Sensors | pcs | 3 | 3 | 3 | 4 | 4 | 4 | 4 | 4 | 6 | 6 | 6 | 6 |
| Helix Number | pcs | 1 | 1 | 1 | 1 | 1 | 2 | 2 | 2 | 2 | 2 | 2 | 3 |
| Helix Circuit | rpm/min | 50 | 32 | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 30 |
| Helix Blade Number | pcs | 4 Big | 5 Big | 8 Big | 9 Big | 9 Big | 18 Big | 18 Big | 18 Big | 20 Big | 20 Big | 20 Big | 30 Big |
| Fixed Blade Number | pcs | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Required Power | kw/hp | 30/40 | 40/55 | 55/60 | 60/80 | 65/90 | 70/95 | 70/95 | 100/110 | 100/120 | 100/120 | 120/130 | 130/150 |
| Tyre Dimensions | inch | 10.75/15.3 | 10.75/15.3 | 10.75/15.3 | 10.75/15.3 | 400/60-15.3 | 400/60-15.3 | 400/60-15.3 | 400/60-15.3 | 400/60-15.3 | 400/60-15.3 | 400/60-15.3 | 400/60-15.3 |
| TECHNICAL SPECIFICATIONS | UNIT | MOLARIS 10 |
|---|---|---|
| Volume | m3 | 10 |
| Width | mm | 2350 |
| Length | mm | 5700 |
| Height | mm | 2820 |
| Težina | kg | 4100 |
| Max. Loaded Weight | kg | 7000 |
| Scale System | Optional | |
| Scale System Sensors | pcs | 4 |
| Helix Number | pcs | 1 |
| Helix Circuit | rpm/min | 30 |
| Helix Blade Number | pcs | 9 Big |
| Fixed Blade Number | pcs | 2 |
| Potrebna snaga | kw/hp | 60/80 |
| Dimenzije guma | inch | 10.75/15.3 |
| TECHNICAL SPECIFICATIONS | UNIT | MOLARIS 12 |
|---|---|---|
| Volume | m3 | 12 |
| Width | mm | 2350 |
| Length | mm | 5800 |
| Height | mm | 3050 |
| Težina | kg | 4200 |
| Max. Loaded Weight | kg | 7800 |
| Scale System | Optional | |
| Scale System Sensors | pcs | 4 |
| Helix Number | pcs | 1 |
| Helix Circuit | rpm/min | 30 |
| Helix Blade Number | pcs | 9 Big |
| Fixed Blade Number | pcs | 2 |
| Potrebna snaga | kw/hp | 65/90 |
| Dimenzije guma | inch | 400/60-15.3 |
| TECHNICAL SPECIFICATIONS | UNIT | MOLARIS 12D |
|---|---|---|
| Volume | m3 | 12 |
| Width | mm | 2200 |
| Length | mm | 6200 |
| Height | mm | 2730 |
| Težina | kg | 4850 |
| Max. Loaded Weight | kg | 7800 |
| Scale System | Optional | |
| Scale System Sensors | pcs | 4 |
| Helix Number | pcs | 2 |
| Helix Circuit | rpm/min | 30 |
| Helix Blade Number | pcs | 18 Big |
| Fixed Blade Number | pcs | 2 |
| Potrebna snaga | kw/hp | 70/95 |
| Dimenzije guma | inch | 400/60-15.3 |
| TECHNICAL SPECIFICATIONS | UNIT | MOLARIS 14D |
|---|---|---|
| Volume | m3 | 14 |
| Width | mm | 2300 |
| Length | mm | 6620 |
| Height | mm | 2750 |
| Težina | kg | 5000 |
| Max. Loaded Weight | kg | 9200 |
| Scale System | Optional | |
| Scale System Sensors | pcs | 4 |
| Helix Number | pcs | 2 |
| Helix Circuit | rpm/min | 30 |
| Helix Blade Number | pcs | 18 Big |
| Fixed Blade Number | pcs | 2 |
| Potrebna snaga | kw/hp | 70/95 |
| Dimenzije guma | inch | 400/60-15.3 |
| TECHNICAL SPECIFICATIONS | UNIT | MOLARIS 16D |
|---|---|---|
| Volume | m3 | 16 |
| Width | mm | 2400 |
| Length | mm | 7000 |
| Height | mm | 2850 |
| Težina | kg | 5250 |
| Max. Loaded Weight | kg | 10000 |
| Scale System | Optional | |
| Scale System Sensors | pcs | 4 |
| Helix Number | pcs | 2 |
| Helix Circuit | rpm/min | 30 |
| Helix Blade Number | pcs | 18 Big |
| Fixed Blade Number | pcs | 2 |
| Potrebna snaga | kw/hp | 100/110 |
| Dimenzije guma | inch | 400/60-15.3 |
| TECHNICAL SPECIFICATIONS | UNIT | MOLARIS 18D |
|---|---|---|
| Volume | m3 | 18 |
| Width | mm | 2400 |
| Length | mm | 7200 |
| Height | mm | 2850 |
| Težina | kg | 5750 |
| Max. Loaded Weight | kg | 11000 |
| Scale System | Optional | |
| Scale System Sensors | pcs | 6 |
| Helix Number | pcs | 2 |
| Helix Circuit | rpm/min | 30 |
| Helix Blade Number | pcs | 20 Big |
| Fixed Blade Number | pcs | 2 |
| Potrebna snaga | kw/hp | 100/120 |
| Dimenzije guma | inch | 400/60-15.3 |
| TECHNICAL SPECIFICATIONS | UNIT | MOLARIS 20D |
|---|---|---|
| Volume | m3 | 20 |
| Width | mm | 2400 |
| Length | mm | 7500 |
| Height | mm | 2870 |
| Težina | kg | 6000 |
| Max. Loaded Weight | kg | 12000 |
| Scale System | Optional | |
| Scale System Sensors | pcs | 6 |
| Helix Number | pcs | 2 |
| Helix Circuit | rpm/min | 30 |
| Helix Blade Number | pcs | 20 Big |
| Fixed Blade Number | pcs | 2 |
| Potrebna snaga | kw/hp | 100/120 |
| Dimenzije guma | inch | 400/60-15.3 |
| TECHNICAL SPECIFICATIONS | UNIT | MOLARIS 24D |
|---|---|---|
| Volume | m3 | 24 |
| Width | mm | 2450 |
| Length | mm | 7500 |
| Height | mm | 3000 |
| Težina | kg | 6500 |
| Max. Loaded Weight | kg | 14000 |
| Scale System | Optional | |
| Scale System Sensors | pcs | 6 |
| Helix Number | pcs | 2 |
| Helix Circuit | rpm/min | 30 |
| Helix Blade Number | pcs | 20 Big |
| Fixed Blade Number | pcs | 2 |
| Potrebna snaga | kw/hp | 120/130 |
| Dimenzije guma | inch | 400/60-15.3 |
| TECHNICAL SPECIFICATIONS | UNIT | MOLARIS 3 |
|---|---|---|
| Volume | m3 | 3 |
| Width | mm | 1565 |
| Length | mm | 3900 |
| Height | mm | 2125 |
| Težina | kg | 1400 |
| Max. Loaded Weight | kg | 2300 |
| Scale System | Optional | |
| Scale System Sensors | pcs | 3 |
| Helix Number | pcs | 1 |
| Helix Circuit | rpm/min | 50 |
| Helix Blade Number | pcs | 4 Big |
| Fixed Blade Number | pcs | 2 |
| Potrebna snaga | kw/hp | 30/40 |
| Dimenzije guma | inch | 10.75/15.3 |
| TECHNICAL SPECIFICATIONS | UNIT | MOLARIS 30T |
|---|---|---|
| Volume | m3 | 30 |
| Width | mm | 2500 |
| Length | mm | 9850 |
| Height | mm | 3000 |
| Težina | kg | 8000 |
| Max. Loaded Weight | kg | 17000 |
| Scale System | Optional | |
| Scale System Sensors | pcs | 6 |
| Helix Number | pcs | 3 |
| Helix Circuit | rpm/min | 30 |
| Helix Blade Number | pcs | 30 Big |
| Fixed Blade Number | pcs | 2 |
| Potrebna snaga | kw/hp | 130/150 |
| Dimenzije guma | inch | 400/60-15.3 |
| TECHNICAL SPECIFICATIONS | UNIT | MOLARIS 6 |
|---|---|---|
| Volume | m3 | 6 |
| Width | mm | 2070 |
| Length | mm | 4200 |
| Height | mm | 2500 |
| Težina | kg | 2200 |
| Max. Loaded Weight | kg | 4000 |
| Scale System | Optional | |
| Scale System Sensors | pcs | 3 |
| Helix Number | pcs | 1 |
| Helix Circuit | rpm/min | 32 |
| Helix Blade Number | pcs | 5 Big |
| Fixed Blade Number | pcs | 2 |
| Potrebna snaga | kw/hp | 40/55 |
| Dimenzije guma | inch | 10.75/15.3 |
| TECHNICAL SPECIFICATIONS | UNIT | MOLARIS 8 |
|---|---|---|
| Volume | m3 | 8 |
| Width | mm | 2100 |
| Length | mm | 5100 |
| Height | mm | 2800 |
| Težina | kg | 3850 |
| Max. Loaded Weight | kg | 6850 |
| Scale System | Optional | |
| Scale System Sensors | pcs | 3 |
| Helix Number | pcs | 1 |
| Helix Circuit | rpm/min | 30 |
| Helix Blade Number | pcs | 8 Big |
| Fixed Blade Number | pcs | 2 |
| Potrebna snaga | kw/hp | 55/60 |
| Dimenzije guma | inch | 10.75/15.3 |
